MMD-VP Series

Vacuum Modular Desiccant Air Dryer
(60scfm – 735 scfm)

Mikropor MMD-VP Series Modular Vacuum Purge Heatless Desiccant Air Dryers supply high-quality dry air which has -40°C dew point or optionally -70°C dew point to the system with affordable prices and reliable way.

Conditions

Nominal

Maximum

Working Pressure

100 psi

232 psig

Inlet Temperature

95 °F

122 °F

Ambient Temperature

77 °F

122 °F

Pressure Dewpoint

104 °F

Inlet Temperature (°F)	70	80	90	100	105	110	115	120
Factor F1	1.12	1.09	1.06	1.00	0.93	0.86	0.80	0.75
Pressure (psig)	50	60	70	80	90	100	110	120	130	140	150	175	200	225	230
Factor F3	0.56	0.65	0.74	0.83	0.91	1	1.06	1.08	1.12	1.16	1.20	1.29	1.37	1.45	1.52
